Joint Strike Missile
TypeAir-launched anti-ship or land attack cruise missile
Place of originNorway & United States
Production history
ManufacturerKongsberg Defence & Aerospace
Raytheon Missiles & Defense
Specifications
Mass416 kg (917 lb)
Length4 m (13 ft 1 in)
Width480 mm (1 ft 7 in) stowed
Height520 mm (1 ft 8 in)
WarheadBlast-fragmentation
Warhead weight120 kg (260 lb)
Detonation
mechanism
Time delay, impact
EngineWilliams International F‐415 small turbofan
Operational
range
  • 555 km (345 mi; 300 nmi) hi‐hi‐lo
  • >275 km (171 mi; 148 nmi)[1]
  • 185 km (115 mi; 100 nmi) lo‐lo‐lo
Maximum speed Mach 0.9 (310 m/s; 1,000 ft/s) estimated
Guidance
system
GPS, INS, TERCOM
AccuracyCEP 1 m (3 ft 3 in)
Launch
platform
F-35, F-16, F/A-18E/F, and F-15E
ReferencesJanes[2]

The Joint Strike Missile (JSM) is a multi-role, air-launched cruise missile under development by the Norwegian company Kongsberg Defence & Aerospace and American company Raytheon Missiles & Defense. The JSM is derived from the Naval Strike Missile.

Development

A development of the Naval Strike Missile (NSM), the Joint Strike Missile (JSM) will feature an option for ground strike and a two-way communications line, so that the missile can communicate with the central control room or other missiles in the air. This missile will be integrated with the Lockheed Martin F-35 Lightning II. Studies have shown that the F-35 would be able to carry two of these in its internal bays, while four additional missiles could be carried externally.

Lockheed Martin and Kongsberg signed a joint-marketing agreement for this air-launched version of the NSM, as well as an agreement committing both parties to integrating the JSM on the F-35 platform.[3][4] The project is funded by Norway and Australia.[5] Kongsberg signed a contract for the first phase of development of the JSM in April, 2009, which is scheduled for completion within 18 months.[6] The JSM will have multicore computers running Integrity real-time operating system from Green Hills Software.[7]

Improved features for the Joint Strike Missile include:

  • Larger warhead.[8]
  • Shape changed to fit in F-35 internal bay[9]
  • Ability to attack sea and land based targets
  • Aerial launch platform (F-35)
  • Improved range over NSM, estimates include 150 nmi (170 mi; 280 km)[9] to >100 nmi low-low or > 300 nmi (350 mi; 560 km) hi-low flight profiles[10]
  • Long-term, production start in 2023[11]

In November 2015, an F-16 Fighting Falcon successfully completed live-fire testing of the JSM at the Utah Test and Training Range.[12][13]

Other variants

Kongsberg were studying methods to deploy the JSM from Norway's submarines,[14] and found shaping the missile to fit into the F-35's confined bomb-bay also enabled it to fit in the Mark 41 Vertical Launching System. A VL-JSM could also compete with the Lockheed LRASM for the U.S. Navy's OASuW Increment 2 for a ship-launched anti-ship missile.[15] On 15 July 2014, Kongsberg and Raytheon announced that they had formed a teaming agreement to offer the JSM to the United States Navy for their Offensive Anti-Surface Warfare (OASuW) requirement;[16] Raytheon would produce JSMs for the American market.[17] The Navy plans to begin a competition for the OASuW requirement in 2017, which will likely pit the Kongsberg/Raytheon JSM against the Lockheed Martin AGM-158C LRASM.[18]

Operators

Future Operators

 Norway

The Royal Norwegian Air Force ordered JSM to their fleet of F-35 fighters in October 2021. Expected delivery to be in 2023.[19][20] Integration of the JSM with the F-35, and testing in the United States is facilitated by Lone Star Analysis, under long term contract with the Norwegian Ministry of Defense.[21]

 Japan

In March 2019, Kongsberg was awarded a contract to supply the Japan Air Self-Defense Force with initial deliveries of the joint strike missile.[22] The missiles are expected to arrive in April 2021.[23]

 Finland

In December 2021, the Finnish Air Force selected F-35 as their future fighter jet, and have selected JSM among other weaponry.[24]

 United States

In the Department of Defense's FY 2024 budget request, the United States Air Force intends to procure 268 JSMs over a five year period with the initial order of 48 missiles for FY2024.[25][26]

Potential operators

 Australia

Australia expressed interest in buying the JSM in June 2014 to equip their F-35 fighters. The 2023 Defence Strategic Review, recommended the Joint Strike Missile be integrated into Australia's F-35A's.[27] The missile has also been pitched to South Korea and Japan, and Kongsberg is expected to attempt to make sales to other countries that have ordered the F-35A. The JSM is expected to become fully operational in 2025.[28] Development is aimed to be completed in 2017 and achievement of initial operational capability (IOC) is expected in 2021 with the release of the F-35's Block 4 software. Fit checks have been performed on the external hardpoints of all F-35 variants, and internally on the F-35A and C-models. Countries that operate other aircraft have expressed interest in the JSM, and fit checks have also been performed on the F-15E Strike Eagle and F/A-18E/F Super Hornet, but integration on other platforms will not be conducted without a confirmed customer.[29]

On 15 September 2015 the Australian government signed an agreement to finance the development of a passive radio frequency seeker to complement the existing infrared target seeker.[30]

The 2023 Australian Defence Strategic Review (DSR) recommended that the RAAF acquire JSM for its F-35As and F/A-18F Super Hornets. The Albanese government agreed "in principle" to the recommendation. [31]
